FTTH Drop Cable Production: How the Manufacturing Process Works
Quick fact: more than seventy percent of new U.S. broadband builds now depend on fiber networks that demand tight manufacturing control to meet performance goals.
Shanghai Weiye OFC Equipment manages complete Fiber cable sheathing line manufacturing, from sourcing brand fibers like Fujikura or Corning SMF-28e to complete test reports that guarantee full quality assurance.
Our drop cable designs are built for aerial, underground, and direct-buried installation, with LSZH, PVC, and PE jacket options and configurations from 1 to 4 cores. We offer single-mode OS1/OS2 and OM2–OM4 grades plus G.652D and G.657 variants, Pantone sheath colors, and custom logo printing.
Automation and precision equipment stabilize line speed and maximize repeatability. Typical lead times are four to five days for orders < 100 km and 7–10 days under 500 km, with an MOQ of 1 km and warranty for free replacement on quality issues.
Continue to understand how our materials, tests, and support combine to lower lifecycle cost and pair the right product with your network.
- Shanghai Weiye OFC Equipment delivers full manufacturing with lab validation for U.S. deployments.
- Multiple jacket choices and optical grades cover different install environments.
- Automated lines and machines deliver stable quality and reliable optical performance.
- Quick lead times, low minimums, and brand fiber options support reliable procurement planning.
- Complete reports and after-sales warranty back product reliability and compliance documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When project timelines and performance matter, Shanghai Weiye OFC Equipment delivers tailored drop solutions with full test documentation.
As a focused supplier and manufacturer, Shanghai Weiye OFC Equipment combines specialized equipment with stringent material control. We provide custom builds and services for residential/MDU deployments. Every order comes with full QA coverage and complete test reports.
Our lab performs high heat, salt-fog, and vibration tests to verify durability. Jacket options include LSZH, PVC, and PE. Designs cover bow-type flat and figure-8/self-supporting styles and use brand fibers such as Fujikura® and Corning® SMF-28e.
- Controlled production lines and in-process checks for shipments with audit trails.
- Technical support for requirements, pilots, and scaling.
- Modern fixtures and calibration minimize variation so every cable meets operator standards.
FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, pairing brand fiber choices with rigorous test routines.
Optical fiber selection and brand options
We match fiber ribbon line to minimum bend radius, attenuation, and deployment type. Options include OS1, OS2, OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura® and Corning SMF-28e are available to meet procurement standards.
Strength member integration
Strength members employ FRP (dielectric) or metallic steel wire. FRP is preferred where non-conductive runs are required. Steel wire provides tensile strength for long-span aerial runs and grounding needs.
Jacket Options and Control
Jacket options include LSZH for indoor flame safety, PVC for flexibility and ease of handling, and PE for UV/moisture resistance outdoors. Tight process control of extruder temperature and capstan speed keeps line speed stable and critical dimensions.
| Member | FRP | Metallic Steel |
|---|---|---|
| Use case | Non-conductive runs | High-tension aerial runs |
| Advantage | Light, non-corrosive | High strength |
| Installation note | Easier terminations | Bonding/grounding required |
Inline and final testing
Inline geometry/concentricity checks operate in-line. Final optical tests confirm attenuation and reflectance. Each order includes a full test report and lab results from high heat, salt-spray, and vibration tests to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Lot records and first-article approvals provide traceability and compliance for U.S. projects.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment provides a compact portfolio of drop designs that fit indoor risers and long aerial runs. Each option pairs tested materials with geometry tuned for field termination and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It reduces bend loss for simple routing in hallways and MDUs.
Self-supporting designs for aerial spans
Self-supporting FTTH drop designs use a support messenger to carry tensile loads. Choose dielectric FRP for non-conductive runs or steel wire when bonding/grounding and higher tensile strength are required.
Layouts & Strength Members
We provide both dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and flat unitube types balance crush resistance and fiber ribbone line for fast terminations.
Indoor/outdoor jackets
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each series is validated for mechanical and optical quality before shipment.
| Design | Application | Strength element | Sheath |
|---|---|---|---|
| Flat bow-type | Indoor risers and MDUs | FRP (dielectric) | Low-smoke zero-halogen |
| Self-supporting (aerial) | Overhead spans | Steel wire or FRP | Polyethylene |
| Center loose tube | Higher-count builds | Dielectric FRP | LSZH or PE |
| Flat unitube | Low-count, easy strip | FRP/Steel | LSZH/PE |
Production line equipment that ensures quality and speed
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and boost throughput for patch cord prep.
Our production line uses automated machines that cut and strip drop patch cords to raise throughput and reduce operator variability.
The CLX-BPO2 auto-stripping machine uses PLC + photoelectric control. One cycle is ~1.5 s, giving ~20 terminals per minute in production.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP/steel members to precise reserved lengths. Pneumatic cylinder actuators deliver fast, repeatable motion and minimize downtime.
Closed-Loop Control for Repeatability
PLC logic and photoelectric sensors give exact positioning and closed-loop control. Inline checks update SPC charts so operators can adjust drifts before out-of-control conditions occur.
| Feature | Capability | Result |
|---|---|---|
| Machine | 1.5s cycle, auto-strip | High throughput |
| Drive | Pneumatic cylinders | Fast/reliable motion |
| Material handling | LSZH & PVC; FRP & steel | Accurate stubs, clean terminations |
| Process control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Automated waste ejection and ergonomic feeders keep the line clean.
- Process control plans document calibration and key parameters.
- Integrated assets and trained operators support FTTH volume targets without compromising accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, reducing cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC and photoelectric control enable precise detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Line Speed
Typical operation speed is 1.5s per cycle. This translates to steady throughput under normal production conditions.
Supported jacket and reserved strength lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to fit common termination hardware.
Cutting FRP/Steel Members
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Customized cutters are offered for nonstandard sizes to preserve precision.
- Auto-eject scrap and sensor-triggered start reduce idle time.
- Compact size (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg weight ease integration into workcells.
- Cylinder-driven motion and PLC/photoelectric control improve line reliability and lower maintenance interruptions.
| Spec | Value | Why it matters |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | Supports high-volume runs |
| Strip lengths (A) | 17.5 to 35.0 mm | Fits common connector processes |
| Stub (B) | 7.0–11.0 mm | Supports termination strength |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without compromising quality.
Customized specifications to fit your FTTH system
Shanghai Weiye OFC Equipment configures every order to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1 to 4 cores with SM or MM fiber. Options include OS1, OS2, and OM2–OM4 along with G.652D/G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tags.
Jacket materials, print legends, and branding
Select LSZH/PVC/PE jackets based on route and safety rules. Custom print legends and logos aid inventory/warranty tracking.
Length options, packaging, and special structures
Standard put-ups are 1/2/4 km with custom reels and packaging to suit storage and handling. Choose flat bow-type or self-supporting and FRP or steel members to meet span and isolation needs.
| Choice | Common choice | Benefit |
|---|---|---|
| Length | 1 / 2 / 4 km | Less staging, easier reels |
| Jacket | LSZH, PE, PVC | Indoor/outdoor compatibility |
| Structure | Flat bow / Self-supporting | Flexible routing/span |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and delivers documentation that lists final specifications for easy on-site QA.
QA, Testing & Documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item ships with recorded acceptance data.
Lab Testing: Heat, Salt Spray & Vibration
Our lab conducts elevated-temperature exposure, salt spray corrosion, and mechanical vibration to qualify materials and assemblies. These tests simulate field stresses for indoor/outdoor applications.
100% test reports for every cable
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Traceability & Compliance
Lot/batch records link tests to reels/serials so audits and claims are easy to verify. Documentation uses standard customer templates to accelerate approvals and receiving inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include spec confirmation and formatted test data for rapid review.
- Continuous test trends inform preventive maintenance and improve long-term reliability.
| Test | Purpose | Result |
|---|---|---|
| Heat exposure | Thermal stability | Pass at target temperature |
| Salt spray | Corrosion robustness | Outdoor suitability |
| Mechanical vibration | Resistance to vibration | Improved field reliability |
Pricing and cost drivers for FTTH drop cable
Budget planning for a drop starts with fiber and jacket choices and is shaped by volume and customization.
Typical prices range broadly—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, reel length, and design structure.
Materials, Grade, Jacket & Structure
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting structures and steel strength elements raise material and labor input. Custom colors, logos, and print legends add setup and impact pricing on small runs.
How Volume & Options Affect Cost
Longer put-ups and larger volumes reduce unit cost. Small quantities often include setup charges and higher per-unit charges.
- Changeovers and special cutters extend lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets over phases.
| Factor | Price impact | Recommendation |
|---|---|---|
| Optical grade | Large | Balance spec vs. budget |
| Sheath material | Medium impact | Evaluate LSZH vs PE |
| Length/Volume | High impact | Consolidate runs to cut unit cost |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align crews and sites. Predictable schedules reduce downtime and control costs when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We schedule line capacity to track your milestones and to maintain on-time delivery.
The service team provides updates/tracking so installation teams know when reels arrive. For tight schedules, we reserve contingency capacity to pull in critical-path orders.
Why MOQ Matters
The MOQ is one kilometer. This reflects setup needs such as wire and jacket die adjustments that consume start-up material and scrap.
We review your length and staging plans to choose reel sizes that cut waste and handling. Batch releases can balance inventory holding with more frequent small-site deliveries.
Where and How to Deploy
Site conditions dictate whether a self-supporting aerial, duct pull, or direct burial is the right choice for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to manage sag/tension for long-term stability.
Duct installations work best with low-friction jackets and crush-resistant constructs so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor riser/plenum distribution and ONT termination
Indoor riser and plenum routes prefer LSZH to meet smoke/flame codes. Flat drop profiles strip cleanly and present controlled strength stubs for fast ONT terminations.
We advise on steel vs FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware fit. Standardized line prep reduces install time and reduces scrap.
| Deployment | Key design | Installer note |
|---|---|---|
| Overhead | Self-supporting, steel or FRP | Verify messenger hardware/tension |
| Duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct-buried | PE with moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH with tight-bend support | Maintain bend radius at penetrations |
Our approach delivers a consistent installation across indoor outdoor transitions. That leads to fewer callbacks, faster activations, and stable field performance for your system.
Comprehensive Support & After-Sales
Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements through approved drawings and pilot builds. We provide doc templates and clear installation notes so field crews work from the same plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full test reports and traceability to support QA acceptance.
- Round-the-clock availability for status and technical support.
- Warranty includes free replacement for confirmed quality issues.
- Coordination of line schedules for urgent changes or acceleration requests.
- Config control so shipped items match agreed requirements every time.
| Area | Scope | Outcome |
|---|---|---|
| Engineering | Specs + pilots | Reduced field issues |
| QA/Testing | Lab trials & 100% test reports | Full traceability |
| Service | Fast replace + RCA | Lower downtime |
Conclusion
Select Shanghai Weiye OFC Equipment for custom drops, quick lead times, and full traceability.
We provide custom FTTH drops that pair material choices with validated manufacturing and lab testing. Every reel includes a 100% test report and documented lab trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2-enabled prep machines, cuts variability and speeds turnaround. Our equipment set standardize strip and stub lengths so installers get consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to maximize service life. Dedicated support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
